دیتاشیت IRF7309TRPBF
مشخصات دیتاشیت
| نام دیتاشیت |
IRF7309TRPBF
|
| حجم فایل |
71.091
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
11
|
مشخصات
-
RoHS:
true
-
Type:
1PCSN-Channel&1PCSP-Channel
-
Category:
Triode/MOS Tube/Transistor/MOSFETs
-
Datasheet:
Infineon Technologies IRF7309TRPBF
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Power Dissipation (Pd):
1.4W
-
Total Gate Charge (Qg@Vgs):
25nC@4.5V
-
Drain Source Voltage (Vdss):
30V
-
Input Capacitance (Ciss@Vds):
520pF@15V
-
Continuous Drain Current (Id):
4A;3A
-
Gate Threshold Voltage (Vgs(th)@Id):
1V@250uA
-
Reverse Transfer Capacitance (Crss@Vds):
-
-
Drain Source On Resistance (RDS(on)@Vgs,Id):
50mΩ@2.4A,10V
-
Package:
SOP-8
-
Manufacturer:
Infineon Technologies
