دیتاشیت AD5689RBCPZ-RL7

AD5689R, 87R Datasheet

مشخصات دیتاشیت

نام دیتاشیت AD5689R, 87R Datasheet
حجم فایل 1070.916 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

دانلود دیتاشیت AD5689R, 87R Datasheet

AD5689R, 87R Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Analog Devices AD5689RBCPZ-RL7
  • Interface: SPI;DSP
  • Resolution: 16Bit
  • Output Type: Voltage-缓冲
  • Settling Time: 8us
  • Supply Voltage: 1.8V~5.5V
  • Integral nonlinearity: ±1LSB
  • Operating Temperature: -40°C~+105°C
  • Package: LFCSP-16
  • Manufacturer: Analog Devices
  • Series: nanoDAC+®
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Number of Bits: 16
  • Number of D/A Converters: 2
  • Differential Output: No
  • Data Interface: SPI, DSP
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: 2.7V ~ 5.5V
  • Voltage - Supply, Digital: 1.8V ~ 5.5V
  • INL/DNL (LSB): ±1, ±1 (Max)
  • Architecture: String DAC
  • Package / Case: 16-WFQFN Exposed Pad, CSP
  • Supplier Device Package: 16-LFCSP-WQ (3x3)
  • Mounting Type: Surface Mount
  • Base Part Number: AD5689
  • detail: 16 Bit Digital to Analog Converter 2 16-LFCSP-WQ (3x3)
