دیتاشیت MC14081BDR2G
مشخصات دیتاشیت
| نام دیتاشیت | MC14001B Series |
|---|---|
| حجم فایل | 132.779 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 11 |
دانلود دیتاشیت MC14001B Series |
MC14001B Series Datasheet |
|---|
مشخصات
- RoHS: true
- Series: 4000B
- Category: Logic ICs/Gates
- Datasheet: onsemi MC14081BDR2G
- Sink Current: 8.8mA
- Source Current: 8.8mA
- Supply Voltage: 3V~18V
- Logic Gate Type: And
- Number of Channels: 4
- Low Level Range (VIL): 1.5V~4V
- Operating Temperature: -55°C~+125°C
- High Level Range (VIH): 3.5V~11V
- Propagation Delay Time: 100ns@15V,50pF
- Quiescent Current (Max): 1uA
- Package: SOP-14
- Manufacturer: onsemi
- Packaging: Cut Tape (CT)
- Part Status: Active
- Logic Type: AND Gate
- Number of Circuits: 4
- Number of Inputs: 2
- Features: -
- Voltage - Supply: 3V ~ 18V
- Current - Quiescent (Max): 1µA
- Current - Output High, Low: 8.8mA, 8.8mA
- Logic Level - Low: 1.5V ~ 4V
- Logic Level - High: 3.5V ~ 11V
- Max Propagation Delay @ V, Max CL: 100ns @ 15V, 50pF
- Mounting Type: Surface Mount
- Supplier Device Package: 14-SOIC
- Package / Case: 14-SOIC (0.154", 3.90mm Width)
- Base Part Number: MC14081
- detail: AND Gate IC 4 Channel 14-SOIC
