دیتاشیت LM393M

مشخصات دیتاشیت

دانلود دیتاشیت LM193,293,393,2903 Datasheet	LM193,293,393,2903 Datasheet Datasheet

RoHS: true
Category: Operational Amplifier/Comparator/Comparators
Datasheet: Texas Instruments LM393M
Output Type: 开集;轨到轨
Supply Current: 2.5mA
Supply Voltage: 2V~36V;1V~18V
Number of Elements: 2
Operating Temperature: 0°C~+70°C
Propagation Delay Time: 700ns
Input Bias Current (Ib): 0.25uA
Input Offset Voltage (Vos): 5mV
Input Hysteresis Voltage (Vhys): -
Common Mode Rejection Ratio (CMRR): -
Package: SOP-8
Manufacturer: Texas Instruments
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Propagation Delay (Max): 700ns
Current - Quiescent (Max): 2.5mA
Voltage - Input Offset (Max): 5mV @ 30V
Part Status: Active
Current - Output (Typ): 16mA @ 5V
Current - Input Bias (Max): 0.25µA @ 5V
Packaging: Tube
Type: General Purpose
CMRR, PSRR (Typ): -
Voltage - Supply, Single/Dual (±): 2V ~ 36V, ±1V ~ 18V
Series: -
Base Part Number: LM393
Supplier Device Package: 8-SOIC
Mounting Type: Surface Mount
Hysteresis: -
detail: Comparator General Purpose CMOS, DTL, ECL, MOS, Open-Collector, TTL 8-SOIC
