دیتاشیت MJW3281A

مشخصات دیتاشیت

دانلود دیتاشیت MJW3281A, 1302A	MJW3281A, 1302A Datasheet

RoHS: true
Category: Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
Datasheet: SPTECH MJW3281A
Transistor Type: NPN
Operating Temperature: +150°C@(Tj)
Collector Current (Ic): 15A
Power Dissipation (Pd): 200W
Transition Frequency (fT): -
DC Current Gain (hFE@Ic,Vce): 50@1A,5V
Collector Cut-Off Current (Icbo): 50uA
Collector-Emitter Breakdown Voltage (Vceo): 250V
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib): 2V@10A,1A
Package: TO-3PN
Manufacturer: SPTECH
Series: -
Packaging: Tube
Part Status: Obsolete
Current - Collector (Ic) (Max): 15A
Voltage - Collector Emitter Breakdown (Max): 230V
Vce Saturation (Max) @ Ib, Ic: 2V @ 1A, 10A
Current - Collector Cutoff (Max): 50µA (ICBO)
DC Current Gain (hFE) (Min) @ Ic, Vce: 50 @ 7A, 5V
Power - Max: 200W
Frequency - Transition: 30MHz
Mounting Type: Through Hole
Package / Case: TO-247-3
Supplier Device Package: TO-247
Base Part Number: MJW32
detail: Bipolar (BJT) Transistor NPN 230V 15A 30MHz 200W Through Hole TO-247
