دیتاشیت MJ15022G
مشخصات دیتاشیت
| نام دیتاشیت |
MJ15022, 24
|
| حجم فایل |
114.289
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
4
|
مشخصات
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Tray
-
Part Status:
Active
-
Transistor Type:
NPN
-
Current - Collector (Ic) (Max):
16A
-
Voltage - Collector Emitter Breakdown (Max):
200V
-
Vce Saturation (Max) @ Ib, Ic:
4V @ 3.2A, 16A
-
Current - Collector Cutoff (Max):
500µA
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
15 @ 8A, 4V
-
Power - Max:
250W
-
Frequency - Transition:
4MHz
-
Operating Temperature:
-65°C ~ 200°C (TJ)
-
Mounting Type:
Through Hole
-
Package / Case:
TO-204AA, TO-3
-
Supplier Device Package:
TO-204 (TO-3)
-
Base Part Number:
MJ150
-
detail:
Bipolar (BJT) Transistor NPN 200V 16A 4MHz 250W Through Hole TO-204 (TO-3)
