دیتاشیت NSS1C200LT1G
مشخصات دیتاشیت
| نام دیتاشیت |
NSS1C200LT1G
|
| حجم فایل |
132.521
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
6
|
مشخصات
-
RoHS:
true
-
Category:
Triode/MOS Tube/Transistor/Bipolar Transistors - BJT
-
Datasheet:
onsemi NSS1C200LT1G
-
Transistor Type:
PNP
-
Operating Temperature:
-55°C~+150°C@(Tj)
-
Collector Current (Ic):
2A
-
Power Dissipation (Pd):
490mW
-
Transition Frequency (fT):
120MHz
-
DC Current Gain (hFE@Ic,Vce):
120@50mA,2V
-
Collector Cut-Off Current (Icbo):
100nA
-
Collector-Emitter Breakdown Voltage (Vceo):
100V
-
Collector-Emitter Saturation Voltage (VCE(sat)@Ic,Ib):
250mV@200mA,2A
-
Package:
SOT-23(TO-236)
-
Manufacturer:
onsemi
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Current - Collector (Ic) (Max):
2A
-
Voltage - Collector Emitter Breakdown (Max):
100V
-
Vce Saturation (Max) @ Ib, Ic:
250mV @ 200mA, 2A
-
Current - Collector Cutoff (Max):
100nA (ICBO)
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
120 @ 50mA, 2V
-
Power - Max:
490mW
-
Frequency - Transition:
120MHz
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
SOT-23-3 (TO-236)
-
Base Part Number:
NSS1C2
-
detail:
Bipolar (BJT) Transistor PNP 100V 2A 120MHz 490mW Surface Mount SOT-23-3 (TO-236)
