NCV7805BDTRKG دیتاشیت

NCV7805BDTRKG

مشخصات دیتاشیت

نام دیتاشیت NCV7805BDTRKG
حجم فایل 100.017 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

دانلود دیتاشیت NCV7805BDTRKG

دانلود دیتاشیت

سایر مستندات

MC78zz(z), NCV78zz 33 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: onsemi NCV7805BDTRKG
  • Output Type: Fixed
  • Output Current: 1A
  • Output Voltage: 5V
  • Dropout Voltage: 2V@(1A)
  • Output Polarity: Positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 35V
  • Operating Temperature: -40°C~+125°C
  • Quiescent Current (Ground Current): 8mA
  • Power Supply Rejection Ratio (PSRR): 83dB@(120Hz)
  • Package: TO-252
  • Manufacturer: onsemi
  • Series: Automotive, AEC-Q100
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Number of Regulators: 1
  • Voltage - Input (Max): 35V
  • Voltage - Output (Min/Fixed): 5V
  • Voltage - Output (Max): -
  • Voltage Dropout (Max): 2V @ 1A (Typ)
  • Current - Output: 1A
  • Current - Quiescent (Iq): 8mA
  • PSRR: 83dB (120Hz)
  • Control Features: -
  • Protection Features: Over Temperature, Short Circuit
  • Mounting Type: Surface Mount
  • Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
  • Supplier Device Package: DPAK
  • Base Part Number: NCV7805
  • detail: Linear Voltage Regulator IC 1 Output 1A DPAK
