دیتاشیت NCV8141D2TR4G
مشخصات دیتاشیت
| نام دیتاشیت |
NCV8141
|
| حجم فایل |
169.109
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
13
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
onsemi NCV8141D2TR4G
-
Output Type:
Fixed
-
Output Current:
500mA
-
Output Voltage:
5V
-
Dropout Voltage:
1.5V@(500mA)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
26V
-
Operating Temperature:
-40°C~+125°C@(Ta)
-
Power Supply Rejection Ratio (PSRR):
75dB@(120Hz)
-
Package:
D2PAK
-
Manufacturer:
onsemi
-
Series:
Automotive, AEC-Q100
-
Packaging:
Tape & Reel (TR)
-
Part Status:
Obsolete
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Voltage - Input (Max):
26V
-
Voltage - Output (Min/Fixed):
5V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
1.5V @ 500mA
-
Current - Output:
500mA
-
PSRR:
75dB (120Hz)
-
Control Features:
Enable, Reset, Watchdog
-
Protection Features:
Over Temperature, Short Circuit
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-263-8, D²Pak (7 Leads + Tab), TO-263CA
-
Supplier Device Package:
D2PAK-7
-
Base Part Number:
NCV8141
-
detail:
Linear Voltage Regulator IC 1 Output 500mA D2PAK-7
