- دیتاشیت LM78M05CT/NOPB
LM78M05CT/NOPB دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | LM78M05CT/NOPB |
|---|---|
| حجم فایل | 73.572 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 23 |
دانلود دیتاشیت LM78M05CT/NOPB |
دانلود دیتاشیت |
|---|
سایر مستندات
LM341/LM78Mxx Series 25 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments LM78M05CT/NOPB
- Output Type: Fixed
- Output Current: 500mA
- Output Voltage: 5V
- Dropout Voltage: -
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 35V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 3mA
- Power Supply Rejection Ratio (PSRR): 78dB@(120Hz)
- Package: TO-220
- Manufacturer: Texas Instruments
- Base Part Number: LM78M05
- Supplier Device Package: TO-220-3
- Voltage - Output (Max): -
- Output Configuration: Positive
- Current - Quiescent (Iq): 3mA
- PSRR: 78dB (120Hz)
- Voltage Dropout (Max): -
- Number of Regulators: 1
- Mounting Type: Through Hole
- Packaging: Tube
- Voltage - Output (Min/Fixed): 5V
- Protection Features: Over Current, Over Temperature, Short Circuit
- Series: -
- Voltage - Input (Max): 35V
- Current - Output: 500mA
- Part Status: Not For New Designs
- Package / Case: TO-220-3
- Control Features: -
- detail: Linear Voltage Regulator IC 1 Output 500mA TO-220-3
