دیتاشیت CD74HC4052E
مشخصات دیتاشیت
| نام دیتاشیت | CDx4HC405x, CDx4HCT405x |
|---|---|
| حجم فایل | 1604.266 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 45 |
دانلود دیتاشیت CDx4HC405x, CDx4HCT405x |
CDx4HC405x, CDx4HCT405x Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
- Datasheet: Texas Instruments CD74HC4052E
- Supply Voltage: 2V~6V
- Switch Circuit: 单刀四掷(SP4T)
- Number of Channels: 2
- On-State Resistance (Max): 130Ω
- Package: PDIP-16
- Manufacturer: Texas Instruments
- Current - Leakage (IS(off)) (Max): 200nA
- Voltage - Supply, Single (V+): 2V ~ 6V
- Voltage - Supply, Dual (V±): ±1V ~ 5V
- Number of Circuits: 2
- Channel-to-Channel Matching (ΔRon): 5Ohm
- Package / Case: 16-DIP (0.300", 7.62mm)
- Part Status: Active
- Supplier Device Package: 16-PDIP
- Switch Time (Ton, Toff) (Max): -
- Packaging: Tube
- -3db Bandwidth: 185MHz
- Operating Temperature: -55°C ~ 125°C (TA)
- Mounting Type: Through Hole
- Crosstalk: -
- Base Part Number: 74HC4052
- Series: -
- Channel Capacitance (CS(off), CD(off)): 12pF
- Multiplexer/Demultiplexer Circuit: 4:1
- Charge Injection: -
- detail: 2 Circuit IC Switch 4:1 130Ohm 16-PDIP
