SMCJ12A 数据手册
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: AnBon SMCJ12A
- Breakdown Voltage: 13.3V
- Maximum Clamping Voltage: 19.9V
- Reverse Stand-Off Voltage (Vrwm): 12V
- Peak Pulse Current (Ipp)@10/1000us: 75.3A
- Package: SMC(DO-214AB)
- Manufacturer: AnBon
- Reverse Leakage Current (Ir): 1uA
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 1500W
- Unidirectional Channels: 1
