SMAJ300A 数据手册
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: MDD(Microdiode Electronics) SMAJ300A
- Package: SMA(DO-214AC)
- Manufacturer: MDD(Microdiode Electronics)
- Breakdown Voltage: 335V
- Maximum Clamping Voltage: 486V
- Reverse Leakage Current (Ir): 1uA
- Reverse Stand-Off Voltage (Vrwm): 300V
- Peak Pulse Current (Ipp)@10/1000us: 0.8A
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 400W
