دیتاشیت ADP151AUJZ-3.3-R7

مشخصات دیتاشیت

دانلود دیتاشیت ADP151 Series	ADP151 Series Datasheet

RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: Analog Devices ADP151AUJZ-3.3-R7
Output Type: Fixed
Output Current: 200mA
Output Voltage: 3.3V
Dropout Voltage: 230mV@(200mA)
Output Polarity: Positive
Number of Outputs: 1
Maximum Input Voltage: 5.5V
Operating Temperature: -40°C~+125°C
Quiescent Current (Ground Current): 20uA
Power Supply Rejection Ratio (PSRR): 70dB@(10kHz),55dB@(100kHz)
Package: SOT-23-5
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Configuration: Positive
Number of Regulators: 1
Voltage - Input (Max): 5.5V
Voltage - Output (Min/Fixed): 3.3V
Voltage - Output (Max): -
Voltage Dropout (Max): 0.23V @ 200mA
Current - Output: 200mA
Current - Quiescent (Iq): 20µA
Current - Supply (Max): 350µA
PSRR: 70dB ~ 55dB (10kHz ~ 100kHz)
Control Features: Enable
Protection Features: Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Mounting Type: Surface Mount
Package / Case: SOT-23-5 Thin, TSOT-23-5
Supplier Device Package: TSOT-5
Base Part Number: ADP151
detail: Linear Voltage Regulator IC 1 Output 200mA TSOT-5
