SMF24A 数据手册
技术规格
- RoHS: true
- Category: TVS/Fuse/Board Level Protection/TVS
- Datasheet: MSKSEMI SMF24A
- Breakdown Voltage: 26.7V
- Maximum Clamping Voltage: 38.9V
- Reverse Leakage Current (Ir): 1uA
- Reverse Stand-Off Voltage (Vrwm): 24V
- Peak Pulse Current (Ipp)@10/1000us: 5.1A
- Peak Pulse Power Dissipation (Ppp)@10/1000us: 200W
- Package: SOD-123FL
- Manufacturer: MSKSEMI
- Unidirectional Channels: 1
- Peak Pulse Current (Ipp)@10/1000μs: 5.1A
