دیتاشیت SN74HC125DR

SN54HC125, SN74HC125

مشخصات دیتاشیت

نام دیتاشیت SN54HC125, SN74HC125
حجم فایل 1346.224 کیلوبایت
نوع فایل pdf
تعداد صفحات 30

دانلود دیتاشیت SN54HC125, SN74HC125

SN54HC125, SN74HC125 Datasheet

مشخصات

  • RoHS: true
  • Category: Logic ICs/Buffer/Driver/Transceiver
  • Datasheet: Texas Instruments SN74HC125DR
  • Input type: -
  • output type: Tri-State
  • Logic Family: 74HC
  • Sink Current: 7.8mA
  • Source Current: 7.8mA
  • Supply Voltage: 2V~6V
  • Number of Elements: 4
  • Operating Temperature: -40°C~+85°C
  • Number of Bits per Element: 1
  • Package: SOP-14
  • Manufacturer: Texas Instruments
  • Part Status: Active
  • Base Part Number: SN74HC1
  • Package / Case: 14-SOIC (0.154", 3.90mm Width)
  • Voltage - Supply: 2V ~ 6V
  • Series: 74HC
  • Mounting Type: Surface Mount
  • Current - Output High, Low: 7.8mA, 7.8mA
  • Packaging: Cut Tape (CT)
  • Supplier Device Package: 14-SOIC
  • Logic Type: Buffer, Non-Inverting
  • detail: Buffer, Non-Inverting 4 Element 1 Bit per Element 3-State Output 14-SOIC
