STS7PF30L* 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: STMicroelectronics
- Series: STripFET™ II
- Packaging: Cut Tape (CT)
- Part Status: Obsolete
- FET Type: P-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 30V
- Current - Continuous Drain (Id) @ 25°C: 7A (Tc)
- Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
- Rds On (Max) @ Id, Vgs: 21mOhm @ 3.5A, 10V
- Vgs(th) (Max) @ Id: 2.5V @ 250µA
- Gate Charge (Qg) (Max) @ Vgs: 38nC @ 4.5V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 2600pF @ 25V
- FET Feature: -
- Power Dissipation (Max): 2.5W (Tc)
- Operating Temperature: 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: 8-SO
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Base Part Number: STS7P
- detail: P-Channel 30V 7A (Tc) 2.5W (Tc) Surface Mount 8-SO
