LM150K Datasheet

LMx50

Datasheet specifications

Datasheet's name LMx50
File size 169.102 KB
File type pdf
Number of pages 9

Download Datasheet LMx50

Download Datasheet

Other documentations

No other documentation was found!

Technical specifications

  • Manufacturer: STMicroelectronics
  • Series: -
  • Packaging: Bulk
  • Part Status: Obsolete
  • Output Configuration: Positive
  • Output Type: Adjustable
  • Number of Regulators: 1
  • Voltage - Input (Max): 35V
  • Voltage - Output (Min/Fixed): 1.2V
  • Voltage - Output (Max): 25V
  • Voltage Dropout (Max): -
  • Current - Output: 3A
  • PSRR: 86dB ~ 65dB (120Hz)
  • Control Features: -
  • Protection Features: Over Current, Over Temperature
  • Operating Temperature: -55°C ~ 150°C
  • Mounting Type: Through Hole
  • Package / Case: TO-204AA, TO-3
  • Supplier Device Package: TO-3
  • Base Part Number: LM150
  • detail: Linear Voltage Regulator IC 1 Output 3A TO-3
