STTH1002CB-TR Datasheet
Datasheet specifications
|
Datasheet's name
|
STTH1002CB-TR
|
|
File size
|
54.792
KB
|
|
File type
|
pdf
|
|
Number of pages
|
17
|
Technical specifications
-
RoHS:
true
-
Category:
Diodes/Diodes - General Purpose
-
Datasheet:
STMicroelectronics STTH1002CB-TR
-
Diode Configuration:
Dual Common Cathode
-
Reverse Voltage (Vr):
200V
-
Forward Voltage (Vf@If):
1.1V@5A
-
Reverse Leakage Current:
5uA@200V
-
Average Rectified Current (Io):
8A
-
Package:
TO-252
-
Manufacturer:
STMicroelectronics
-
Series:
Automotive, AEC-Q101
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
200V
-
Current - Average Rectified (Io) (per Diode):
8A
-
Voltage - Forward (Vf) (Max) @ If:
1.1V @ 5A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Reverse Recovery Time (trr):
25ns
-
Current - Reverse Leakage @ Vr:
5µA @ 200V
-
Operating Temperature - Junction:
175°C (Max)
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-252-3, DPak (2 Leads + Tab), SC-63
-
Supplier Device Package:
DPAK
-
Base Part Number:
STTH10
-
detail:
Diode Array 1 Pair Common Cathode Standard 200V 8A Surface Mount TO-252-3, DPak (2 Leads + Tab), SC-63
