SN54,74HCT74 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
SN54,74HCT74
|
|
حجم فایل
|
1299.849
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
22
|
مشخصات فنی
-
Voltage - Supply:
4.5V ~ 5.5V
-
Part Status:
Active
-
Base Part Number:
SN74HCT
-
Current - Quiescent (Iq):
4µA
-
Package / Case:
14-TSSOP (0.173", 4.40mm Width)
-
Max Propagation Delay @ V, Max CL:
25ns @ 5.5V, 50pF
-
Mounting Type:
Surface Mount
-
Series:
74HCT
-
Input Capacitance:
3pF
-
Number of Elements:
2
-
Type:
D-Type
-
Current - Output High, Low:
4mA, 4mA
-
Trigger Type:
Positive Edge
-
Manufacturer:
Texas Instruments
-
Number of Bits per Element:
1
-
Packaging:
Cut Tape (CT)
-
Function:
Set(Preset) and Reset
-
Output Type:
Differential
-
Clock Frequency:
46MHz
-
Supplier Device Package:
14-TSSOP
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
detail:
Flip Flop 2 Element D-Type 1 Bit Positive Edge 14-TSSOP (0.173", 4.40mm Width)
