NSS20201LT1G دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
NSS20201LT1G
|
|
حجم فایل
|
132.3
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
6
|
مشخصات فنی
-
Manufacturer:
ON Semiconductor
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Transistor Type:
NPN
-
Current - Collector (Ic) (Max):
2A
-
Voltage - Collector Emitter Breakdown (Max):
20V
-
Vce Saturation (Max) @ Ib, Ic:
100mV @ 200mA, 2A
-
Current - Collector Cutoff (Max):
100nA (ICBO)
-
DC Current Gain (hFE) (Min) @ Ic, Vce:
200 @ 500mA, 2V
-
Power - Max:
460mW
-
Frequency - Transition:
150MHz
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
TO-236-3, SC-59, SOT-23-3
-
Supplier Device Package:
SOT-23-3 (TO-236)
-
Base Part Number:
NSS202
-
detail:
Bipolar (BJT) Transistor NPN 20V 2A 150MHz 460mW Surface Mount SOT-23-3 (TO-236)
