دیتاشیت UC2843AN*

مشخصات دیتاشیت

دانلود دیتاشیت UC1842A-45A, UC2842A-45A, UC3842A-45A	UC1842A-45A, UC2842A-45A, UC3842A-45A Datasheet

Output Phases: 1
Series: -
Output Configuration: Positive
Output Type: Transistor Driver
Clock Sync: No
Topology: Boost, Buck, Buck-Boost, Flyback, Forward
Packaging: Tube
Synchronous Rectifier: No
Manufacturer: Texas Instruments
Voltage - Supply (Vcc/Vdd): 7.6V ~ 30V
Function: Step-Up, Step-Down, Step-Up/Step-Down
Supplier Device Package: 8-PDIP
Duty Cycle (Max): 96%
Serial Interfaces: -
Frequency - Switching: Up to 500kHz
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Through Hole
Base Part Number: UC2843
Number of Outputs: 1
Part Status: Active
Control Features: Frequency Control
Package / Case: 8-DIP (0.300", 7.62mm)
detail: Boost, Buck, Buck-Boost, Flyback, Forward Regulator Positive Output Step-Up, Step-Down, Step-Up/Step-Down DC-DC Controller IC 8-PDIP
