UCC37321D دیتاشیت

UCC37321D

مشخصات دیتاشیت

نام دیتاشیت UCC37321D
حجم فایل 90.941 کیلوبایت
نوع فایل pdf
تعداد صفحات 37

دانلود دیتاشیت UCC37321D

دانلود دیتاشیت

سایر مستندات

UCC27321-22, UCC37321-22 36 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: Texas Instruments UCC37321D
  • Fall Time: 20ns
  • Load Type: MOSFET
  • Rise Time: 20ns
  • Supply Voltage: 4V~15V
  • Number of Drivers: 1
  • Driven Configuration: Low Side
  • Operating Temperature: 0°C~+70°C@(Ta)
  • Peak Output Current(sink): 9A
  • Peak Output Current(source): 9A
  • Package: SOP-8
  • Manufacturer: Texas Instruments
  • Channel Type: Single
  • Gate Type: N-Channel, P-Channel MOSFET
  • Rise / Fall Time (Typ): 20ns, 20ns
  • Supplier Device Package: 8-SOIC
  • Mounting Type: Surface Mount
  • Current - Peak Output (Source, Sink): 9A, 9A
  • Input Type: Inverting
  • Base Part Number: UCC373
  • Packaging: Tube
  • Voltage - Supply: 4V ~ 15V
  • Series: -
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Part Status: Active
  • Logic Voltage - VIL, VIH: 1.1V, 2.7V
  • detail: Low-Side Gate Driver IC Inverting 8-SOIC
