ADM3252E دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ADM3252E
|
|
حجم فایل
|
438.703
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
16
|
مشخصات فنی
-
Manufacturer:
Analog Devices Inc.
-
Series:
IsoPower®, iCoupler®
-
Packaging:
Tray
-
Part Status:
Active
-
Technology:
Magnetic Coupling
-
Type:
RS232
-
Isolated Power:
Yes
-
Number of Channels:
4
-
Inputs - Side 1/Side 2:
2/2
-
Channel Type:
Unidirectional
-
Voltage - Isolation:
2500Vrms
-
Common Mode Transient Immunity (Min):
25kV/µs
-
Data Rate:
460Kbps
-
Propagation Delay tpLH / tpHL (Max):
-
-
Pulse Width Distortion (Max):
-
-
Rise / Fall Time (Typ):
2.5ns, 2.5ns
-
Voltage - Supply:
3V ~ 5.5V
-
Operating Temperature:
-40°C ~ 85°C
-
Mounting Type:
Surface Mount
-
Package / Case:
44-LFBGA, CSPBGA
-
Supplier Device Package:
44-CSPBGA (12x12)
-
Base Part Number:
ADM3252
-
detail:
RS232 Digital Isolator 2500Vrms 4 Channel 460Kbps 25kV/µs CMTI 44-LFBGA, CSPBGA
