دیتاشیت AD5421BCPZ-REEL7

AD5421

مشخصات دیتاشیت

نام دیتاشیت AD5421
حجم فایل 822.557 کیلوبایت
نوع فایل pdf
تعداد صفحات 36

دانلود دیتاشیت AD5421

AD5421 Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Analog Devices AD5421BCPZ-REEL7
  • Interface: SPI;DSP
  • Resolution: 16Bit
  • Output Type: Current-缓冲
  • Settling Time: 50us
  • Supply Voltage: 3.17V~3.48V
  • Integral nonlinearity: ±1LSB
  • Operating Temperature: -40°C~+105°C
  • Package: LFCSP-32
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Number of Bits: 16
  • Number of D/A Converters: 1
  • Differential Output: No
  • Data Interface: SPI, DSP
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: 1.71V ~ 5.5V
  • Voltage - Supply, Digital: 3.17V ~ 3.48V
  • INL/DNL (LSB): -, ±1 (Max)
  • Architecture: Cyclic Serial
  • Package / Case: 32-VFQFN Exposed Pad, CSP
  • Supplier Device Package: 32-LFCSP-VQ (5x5)
  • Mounting Type: Surface Mount
  • Base Part Number: AD5421
  • detail: 16 Bit Digital to Analog Converter 1 32-LFCSP-VQ (5x5)
