دیتاشیت M74HC04TTR TSSOP-14

M74HC04

مشخصات دیتاشیت

نام دیتاشیت M74HC04
حجم فایل 444.681 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

دانلود دیتاشیت M74HC04

M74HC04 Datasheet

مشخصات

  • Manufacturer: STMicroelectronics
  • Series: 74HC
  • Packaging: Tape & Reel (TR)
  • Part Status: Obsolete
  • Logic Type: Inverter
  • Number of Circuits: 6
  • Number of Inputs: 6
  • Features: -
  • Voltage - Supply: 2V ~ 6V
  • Current - Quiescent (Max): 1µA
  • Current - Output High, Low: 5.2mA, 5.2mA
  • Logic Level - Low: 0.5V ~ 1.8V
  • Logic Level - High: 1.5V ~ 4.2V
  • Max Propagation Delay @ V, Max CL: 16ns @ 6V, 50pF
  • Operating Temperature: -55°C ~ 125°C
  • Mounting Type: Surface Mount
  • Supplier Device Package: 14-TSSOP
  • Package / Case: 14-TSSOP (0.173", 4.40mm Width)
  • Base Part Number: M74HC04
  • detail: Inverter IC 6 Channel 14-TSSOP
