دیتاشیت MC74HC4852ADR2G SOP-16 آی سی سوییچ

MC74HC4851A, MC74HC4852A

مشخصات دیتاشیت

نام دیتاشیت MC74HC4851A, MC74HC4852A
حجم فایل 209.145 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

دانلود دیتاشیت MC74HC4851A, MC74HC4852A

MC74HC4851A, MC74HC4852A Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Switch Circuit: SP4T
  • Multiplexer/Demultiplexer Circuit: 4:1
  • Number of Circuits: 2
  • On-State Resistance (Max): 400Ohm
  • Channel-to-Channel Matching (ΔRon): -
  • Voltage - Supply, Single (V+): 2V ~ 6V
  • Voltage - Supply, Dual (V±): -
  • Switch Time (Ton, Toff) (Max): -
  • -3db Bandwidth: -
  • Charge Injection: -
  • Channel Capacitance (CS(off), CD(off)): 40pF
  • Current - Leakage (IS(off)) (Max): 100nA
  • Crosstalk: -
  • Operating Temperature: -55°C ~ 125°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 16-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 16-SOIC
  • Base Part Number: MC74HC4852
  • detail: 2 Circuit IC Switch 4:1 400Ohm 16-SOIC
