دیتاشیت UCC38C45DR SOP-8 آی سی سوییچینگ

UCC28C40-45, UCC38C40-45

مشخصات دیتاشیت

نام دیتاشیت UCC28C40-45, UCC38C40-45
حجم فایل 4000.192 کیلوبایت
نوع فایل pdf
تعداد صفحات 55

دانلود دیتاشیت UCC28C40-45, UCC38C40-45

UCC28C40-45, UCC38C40-45 Datasheet

مشخصات

  • Function: Step-Up, Step-Up/Step-Down
  • Packaging: Cut Tape (CT)
  • Series: -
  • Supplier Device Package: 8-SOIC
  • Serial Interfaces: -
  • Topology: Boost, Flyback, Forward Converter
  • Control Features: Frequency Control
  • Part Status: Active
  • Base Part Number: UCC38
  • Synchronous Rectifier: No
  • Clock Sync: No
  • Operating Temperature: 0°C ~ 70°C (TJ)
  • Duty Cycle (Max): 48%
  • Output Configuration: Positive
  • Manufacturer: Texas Instruments
  • Mounting Type: Surface Mount
  • Number of Outputs: 1
  • Output Phases: 1
  • Output Type: Transistor Driver
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Voltage - Supply (Vcc/Vdd): 7.6V ~ 18V
  • Frequency - Switching: Up to 1MHz
  • detail: Boost, Flyback, Forward Converter Regulator Positive Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 8-SOIC
