دیتاشیت BSS123LT1G SOT-23 ماسفت کانال N
مشخصات دیتاشیت
| نام دیتاشیت | BSS123 Datasheet |
|---|---|
| حجم فایل | 278.033 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 5 |
دانلود دیتاشیت BSS123 Datasheet |
BSS123 Datasheet Datasheet |
|---|
مشخصات
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- FET Type: N-Channel
- Technology: MOSFET (Metal Oxide)
- Drain to Source Voltage (Vdss): 100V
- Current - Continuous Drain (Id) @ 25°C: 170mA (Ta)
- Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
- Rds On (Max) @ Id, Vgs: 6Ohm @ 170mA, 10V
- Vgs(th) (Max) @ Id: 2V @ 1mA
- Gate Charge (Qg) (Max) @ Vgs: 2.5nC @ 10V
- Vgs (Max): ±20V
- Input Capacitance (Ciss) (Max) @ Vds: 73pF @ 25V
- FET Feature: -
- Power Dissipation (Max): 360mW (Ta)
- Operating Temperature: -55°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: SOT-23-3
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Base Part Number: BSS123
- detail: N-Channel 100V 170mA (Ta) 360mW (Ta) Surface Mount SOT-23-3
