دیتاشیت APT13GP120BG TO-247 1200V 41A

APT13GP120B,S(G)

مشخصات دیتاشیت

نام دیتاشیت APT13GP120B,S(G)
حجم فایل 416.821 کیلوبایت
نوع فایل pdf
تعداد صفحات 6

دانلود دیتاشیت APT13GP120B,S(G)

APT13GP120B,S(G) Datasheet

مشخصات

  • Manufacturer: Microchip Technology
  • Series: POWER MOS 7®
  • Packaging: Tube
  • Part Status: Active
  • IGBT Type: PT
  • Voltage - Collector Emitter Breakdown (Max): 1200V
  • Current - Collector (Ic) (Max): 41A
  • Current - Collector Pulsed (Icm): 50A
  • Vce(on) (Max) @ Vge, Ic: 3.9V @ 15V, 13A
  • Power - Max: 250W
  • Switching Energy: 115µJ (on), 165µJ (off)
  • Input Type: Standard
  • Gate Charge: 55nC
  • Td (on/off) @ 25°C: 9ns/28ns
  • Test Condition: 600V, 13A, 5Ohm, 15V
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Package / Case: TO-247-3
  • Supplier Device Package: TO-247 [B]
  • detail: IGBT PT 1200V 41A 250W Through Hole TO-247 [B]
