دیتاشیت MC14504BDR2G 14504BG SOP-16 آی سی مبدل سطح ولتاژ
مشخصات دیتاشیت
| نام دیتاشیت | MC14504B |
|---|---|
| حجم فایل | 117.976 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 7 |
دانلود دیتاشیت MC14504B |
MC14504B Datasheet |
|---|
مشخصات
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Translator Type: Voltage Level
- Channel Type: Unidirectional
- Number of Circuits: 1
- Channels per Circuit: 6
- Voltage - VCCA: 3V ~ 18V
- Voltage - VCCB: 3V ~ 18V
- Input Signal: -
- Output Signal: -
- Output Type: Non-Inverted
- Data Rate: -
- Operating Temperature: -55°C ~ 125°C (TA)
- Features: -
- Mounting Type: Surface Mount
- Package / Case: 16-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 16-SOIC
- Base Part Number: MC14504
- detail: Voltage Level Translator Unidirectional 1 Circuit 6 Channel 16-SOIC
