دیتاشیت S3K

S3A-S3N

مشخصات دیتاشیت

نام دیتاشیت S3A-S3N
حجم فایل 167.935 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت S3A-S3N

S3A-S3N Datasheet

مشخصات

  • RoHS: true
  • Category: Diodes/Diodes - General Purpose
  • Datasheet: YFW S3K
  • Diode Configuration: Single
  • Reverse Voltage (Vr): 800V
  • Forward Voltage (Vf@If): 1V@10A
  • Reverse Leakage Current: 5uA
  • Average Rectified Current (Io): 3A
  • Package: SMC(DO-214AB)
  • Manufacturer: YFW
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Diode Type: Standard
  • Voltage - DC Reverse (Vr) (Max): 800V
  • Current - Average Rectified (Io): 3A
  • Voltage - Forward (Vf) (Max) @ If: 1.2V @ 3A
  • Speed: Standard Recovery >500ns, > 200mA (Io)
  • Reverse Recovery Time (trr): 2.5µs
  • Current - Reverse Leakage @ Vr: 5µA @ 800V
  • Capacitance @ Vr, F: 60pF @ 4V, 1MHz
  • Mounting Type: Surface Mount
  • Package / Case: DO-214AB, SMC
  • Supplier Device Package: SMC (DO-214AB)
  • Operating Temperature - Junction: -55°C ~ 150°C
  • Base Part Number: S3K
  • detail: Diode Standard 800V 3A Surface Mount SMC (DO-214AB)
