دیتاشیت ST13005A MJE13005 TO-220 ترانزیستور
مشخصات دیتاشیت
| نام دیتاشیت | ST13005 |
|---|---|
| حجم فایل | 151.591 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
دانلود دیتاشیت ST13005 |
ST13005 Datasheet |
|---|
مشخصات
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Tube
- Part Status: Active
- Transistor Type: NPN
- Current - Collector (Ic) (Max): 4A
- Voltage - Collector Emitter Breakdown (Max): 400V
- Vce Saturation (Max) @ Ib, Ic: 1V @ 1A, 4A
- Current - Collector Cutoff (Max): 1mA
- DC Current Gain (hFE) (Min) @ Ic, Vce: 8 @ 2A, 5V
- Power - Max: 75W
- Frequency - Transition: -
- Operating Temperature: 150°C (TJ)
- Mounting Type: Through Hole
- Package / Case: TO-220-3
- Supplier Device Package: TO-220AB
- Base Part Number: ST13005
- detail: Bipolar (BJT) Transistor NPN 400V 4A 75W Through Hole TO-220AB
