دیتاشیت MBRF20L45CTG TO220FP دیود شاتکی

MBR(F)20L45CTG

مشخصات دیتاشیت

نام دیتاشیت MBR(F)20L45CTG
حجم فایل 325.637 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت MBR(F)20L45CTG

MBR(F)20L45CTG Datasheet

مشخصات

  • Manufacturer: ON Semiconductor
  • Series: SWITCHMODE™
  • Packaging: Tube
  • Part Status: Active
  • Diode Configuration: 1 Pair Common Cathode
  • Diode Type: Schottky
  • Voltage - DC Reverse (Vr) (Max): 45V
  • Current - Average Rectified (Io) (per Diode): 10A
  • Voltage - Forward (Vf) (Max) @ If: 500mV @ 10A
  • Speed: Fast Recovery =< 500ns, > 200mA (Io)
  • Current - Reverse Leakage @ Vr: 500µA @ 45V
  • Operating Temperature - Junction: -55°C ~ 150°C
  • Mounting Type: Through Hole
  • Package / Case: TO-220-3 Full Pack
  • Supplier Device Package: TO-220FP
  • Base Part Number: MBRF20
  • detail: Diode Array 1 Pair Common Cathode Schottky 45V 10A Through Hole TO-220-3 Full Pack
