دیتاشیت VIPER17L VIPER17LN DIP7 DIP-7 SWITCHING CHIP
مشخصات دیتاشیت
| نام دیتاشیت | VIPER17 Datasheet |
|---|---|
| حجم فایل | 2433.183 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 31 |
دانلود دیتاشیت VIPER17 Datasheet |
VIPER17 Datasheet Datasheet |
|---|
مشخصات
- Manufacturer: STMicroelectronics
- Series: VIPer™ plus
- Packaging: Tube
- Part Status: Active
- Output Isolation: Isolated
- Internal Switch(s): Yes
- Voltage - Breakdown: 800V
- Topology: Flyback
- Voltage - Start Up: 14V
- Voltage - Supply (Vcc/Vdd): 8.5V ~ 23.5V
- Duty Cycle: 70%
- Frequency - Switching: 60kHz
- Power (Watts): 10W
- Fault Protection: Current Limiting, Over Temperature, Over Voltage
- Control Features: -
- Operating Temperature: -40°C ~ 150°C (TJ)
- Package / Case: 8-DIP (0.300", 7.62mm), 7 Leads
- Supplier Device Package: 8-DIP
- Mounting Type: Through Hole
- Base Part Number: VIPER17
- detail: Converter Offline Flyback Topology 60kHz 8-DIP
