دیتاشیت MCP4822-E/SN SOP8 آی سی مبدل دیجیتال به انالوگ
مشخصات دیتاشیت
نام دیتاشیت | MCP4802,4812,4822 Datasheet |
---|---|
حجم فایل | 1666.028 کیلوبایت |
نوع فایل | |
تعداد صفحات | 50 |
دانلود دیتاشیت MCP4802,4812,4822 Datasheet |
MCP4802,4812,4822 Datasheet Datasheet |
---|
مشخصات
- Manufacturer: Microchip Technology
- Series: -
- Packaging: Tube
- Part Status: Active
- Number of Bits: 12
- Number of D/A Converters: 2
- Settling Time: 4.5µs (Typ)
- Output Type: Voltage - Buffered
- Differential Output: No
- Data Interface: SPI
- Reference Type: Internal
- Voltage - Supply, Analog: 2.7V ~ 5.5V
- Voltage - Supply, Digital: 2.7V ~ 5.5V
- INL/DNL (LSB): ±4, ±0.25
- Architecture: String DAC
- Operating Temperature: -40°C ~ 125°C
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
- Mounting Type: Surface Mount
- Base Part Number: MCP4822
- detail: 12 Bit Digital to Analog Converter 2 8-SOIC
