دیتاشیت AD1580BRTZ-REEL7

AD1580

مشخصات دیتاشیت

نام دیتاشیت AD1580
حجم فایل 370.072 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت AD1580

AD1580 Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Voltage References
  • Datasheet: Analog Devices AD1580BRTZ-REEL7
  • Tolerance: ±0.08%
  • Output Type: Fixed
  • Output Current: 10mA
  • Output Voltage: 1.225V
  • Reference Type: parallel connection
  • Noise - 10Hz to 10kHz: 20uVrms
  • Operating Temperature: -40°C~+85°C@(TA)
  • Temperature Coefficient: 50ppm/°C
  • Minimum Cathode Current for Regulation: 50uA
  • Package: SOT-23
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Voltage - Output (Min/Fixed): 1.225V
  • Current - Output: 10mA
  • Noise - 0.1Hz to 10Hz: 5µVp-p
  • Voltage - Input: -
  • Current - Supply: -
  • Current - Cathode: 50µA
  • Mounting Type: Surface Mount
  • Package / Case: TO-236-3, SC-59, SOT-23-3
  • Supplier Device Package: SOT-23-3
  • Base Part Number: AD1580
  • detail: Shunt Voltage Reference IC ±0.08% SOT-23-3
