دیتاشیت TLV75712PDRVR
مشخصات دیتاشیت
| نام دیتاشیت | TLV757xxP Datasheet |
|---|---|
| حجم فایل | 2541.379 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 36 |
دانلود دیتاشیت TLV757xxP Datasheet |
TLV757xxP Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments TLV75712PDRVR
- Output Current: 1A
- Output Voltage: 1.2V
- Dropout Voltage: 1.1V@(1A)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 5.5V
- Operating Temperature: -40°C~+125°C@(Tj)
- Package: DFN-6(2x2)
- Manufacturer: Texas Instruments
- Voltage - Input (Max): 5.5V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 1.1V @ 1A
- Output Configuration: Positive
- Series: -
- Base Part Number: TLV757
- Current - Supply (Max): 40µA
- Supplier Device Package: 6-WSON (2x2)
- Mounting Type: Surface Mount
- Voltage - Output (Min/Fixed): 1.2V
- Number of Regulators: 1
- PSRR: 52dB (1kHz ~ 1MHz)
- Output Type: Fixed
- Package / Case: 6-WDFN Exposed Pad
- Packaging: Cut Tape (CT)
- Protection Features: Current Limit, Thermal Shutdown, UVLO
- Control Features: Enable
- Part Status: Active
- Current - Output: 1A
- detail: Linear Voltage Regulator IC 1 Output 1A 6-WSON (2x2)
