دیتاشیت TPS61161DRVR WSON-6 M3 Booster Chip
مشخصات دیتاشیت
| نام دیتاشیت | TPS61160-61 |
|---|---|
| حجم فایل | 2390.33 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 40 |
دانلود دیتاشیت TPS61160-61 |
TPS61160-61 Datasheet |
|---|
مشخصات
- Voltage - Output: 38V
- Type: DC DC Regulator
- Operating Temperature: -40°C ~ 85°C (TA)
- Supplier Device Package: 6-WSON (2x2)
- Base Part Number: TPS611
- Packaging: Cut Tape (CT)
- Mounting Type: Surface Mount
- Topology: Step-Up (Boost)
- Manufacturer: Texas Instruments
- Frequency: 600kHz
- Voltage - Supply (Max): 18V
- Voltage - Supply (Min): 2.7V
- Current - Output / Channel: 700mA (Switch)
- Dimming: PWM
- Part Status: Active
- Series: -
- Applications: Backlight
- Package / Case: 6-WDFN Exposed Pad
- Number of Outputs: 1
- Internal Switch(s): Yes
- detail: LED Driver IC 1 Output DC DC Regulator Step-Up (Boost) PWM Dimming 700mA (Switch) 6-WSON (2x2)
