دیتاشیت TPD4E1U06DCKR CODE:BP* SC70-6 SC70-6

TPD4E1U06

مشخصات دیتاشیت

نام دیتاشیت TPD4E1U06
حجم فایل 1150.628 کیلوبایت
نوع فایل pdf
تعداد صفحات 23

دانلود دیتاشیت TPD4E1U06

TPD4E1U06 Datasheet

مشخصات

  • Applications: Ethernet, HDMI
  • Manufacturer: Texas Instruments
  • Unidirectional Channels: 4
  • Mounting Type: Surface Mount
  • Voltage - Clamping (Max) @ Ipp: 15V (Typ)
  • Voltage - Breakdown (Min): 6.5V
  • Supplier Device Package: SC-70-6
  • Current - Peak Pulse (10/1000µs): 3A (8/20µs)
  • Package / Case: 6-TSSOP, SC-88, SOT-363
  • Capacitance @ Frequency: -
  • Operating Temperature: -40°C ~ 125°C (TA)
  • Base Part Number: TPD4E
  • Power Line Protection: Yes
  • Series: -
  • Part Status: Active
  • Packaging: Cut Tape (CT)
  • Type: Steering (Rail to Rail)
  • Voltage - Reverse Standoff (Typ): 5.5V (Max)
  • Power - Peak Pulse: 45W
  • detail: 15V (Typ) Clamp 3A (8/20µs) Ipp Tvs Diode Surface Mount SC-70-6
