VNQ810M SSOP28 SSOP28 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: STMicroelectronics
- Series: -
- Packaging: Tube
- Part Status: Obsolete
- Switch Type: General Purpose
- Number of Outputs: 4
- Ratio - Input:Output: 1:1
- Output Configuration: High Side
- Output Type: N-Channel
- Interface: On/Off
- Voltage - Load: 5.5V ~ 36V
- Voltage - Supply (Vcc/Vdd): Not Required
- Current - Output (Max): 700mA
- Rds On (Typ): 150mOhm (Max)
- Input Type: Non-Inverting
- Features: Auto Restart, Status Flag
- Fault Protection: Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
- Operating Temperature: -40°C ~ 150°C (TJ)
- Mounting Type: Surface Mount
- Supplier Device Package: 28-SO
- Package / Case: 28-SOIC (0.295", 7.50mm Width)
- Base Part Number: VNQ810
- detail: Power Switch/Driver 1:1 N-Channel 700mA 28-SO
