MOC8104 Datasheet
Datasheet specifications
| Datasheet's name | MOC8104 |
|---|---|
| File size | 84.49 KB |
| File type | |
| Number of pages | 3 |
Download Datasheet MOC8104 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Manufacturer: ON Semiconductor
- Series: -
- Packaging: Tube
- Part Status: Obsolete
- Number of Channels: 1
- Voltage - Isolation: 5300Vrms
- Current Transfer Ratio (Min): 160% @ 10mA
- Current Transfer Ratio (Max): 256% @ 10mA
- Turn On / Turn Off Time (Typ): 2µs, 3µs
- Rise / Fall Time (Typ): 1µs, 2µs
- Input Type: DC
- Output Type: Transistor
- Voltage - Output (Max): 30V
- Current - Output / Channel: 50mA
- Voltage - Forward (Vf) (Typ): 1.15V
- Current - DC Forward (If) (Max): 100mA
- Vce Saturation (Max): 400mV
- Operating Temperature: -55°C ~ 100°C
- Mounting Type: Through Hole
- Package / Case: 6-DIP (0.300", 7.62mm)
- Supplier Device Package: 6-DIP
- Base Part Number: MOC810
- detail: Optoisolator Transistor Output 5300Vrms 1 Channel 6-DIP
