دیتاشیت DSEI12-12A
مشخصات دیتاشیت
| نام دیتاشیت |
DSEI12-12A
|
| حجم فایل |
141.79
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
3
|
مشخصات
-
RoHS:
true
-
Category:
Diodes/Diodes - Fast Recovery Rectifiers
-
Datasheet:
Littelfuse/IXYS DSEI12-12A
-
Diode Configuration:
Single
-
Reverse Voltage (Vr):
1.2kV
-
Operating Temperature:
-40°C~+150°C@(Tvj)
-
Forward Voltage (Vf@If):
2.58V@12A
-
Reverse Leakage Current:
250uA@1.2kV
-
Reverse Recovery Time (trr):
150ns
-
Average Rectified Current (Io):
12A
-
Package:
TO-220-2
-
Manufacturer:
IXYS
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Diode Type:
Standard
-
Voltage - DC Reverse (Vr) (Max):
1200V
-
Current - Average Rectified (Io):
11A
-
Voltage - Forward (Vf) (Max) @ If:
2.6V @ 12A
-
Speed:
Fast Recovery =< 500ns, > 200mA (Io)
-
Current - Reverse Leakage @ Vr:
250µA @ 1200V
-
Capacitance @ Vr, F:
-
-
Mounting Type:
Through Hole
-
Package / Case:
TO-220-2
-
Supplier Device Package:
TO-220AC
-
Operating Temperature - Junction:
-40°C ~ 150°C
-
detail:
Diode Standard 1200V 11A Through Hole TO-220AC
