دیتاشیت SN74AHC123APWR
مشخصات دیتاشیت
| نام دیتاشیت |
SN54/74AHC123A
|
| حجم فایل |
1299.939
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
29
|
مشخصات
-
RoHS:
true
-
Category:
Logic ICs/Monostable Multivibrators
-
Datasheet:
Texas Instruments SN74AHC123APWR
-
Input Type:
Schmitt Trigger
-
Logic Family:
74AHC
-
Sink Current:
8mA
-
Source Current:
8mA
-
Supply Voltage:
2V~5.5V
-
Logic Gate Type:
Monostable
-
Propagation Delay:
7.5ns
-
Number Of Channels:
2
-
OperatingTemperature:
-40°C~+85°C
-
Package:
TSSOP-16
-
Manufacturer:
Texas Instruments
-
Independent Circuits:
2
-
Logic Type:
Monostable
-
Part Status:
Active
-
Operating Temperature:
-40°C ~ 85°C
-
Mounting Type:
Surface Mount
-
Packaging:
Cut Tape (CT)
-
Package / Case:
16-TSSOP (0.173", 4.40mm Width)
-
Current - Output High, Low:
8mA, 8mA
-
Series:
74AHC
-
Base Part Number:
SN74AHC1
-
Supplier Device Package:
16-TSSOP
-
Schmitt Trigger Input:
Yes
-
Voltage - Supply:
2V ~ 5.5V
-
detail:
Monostable Multivibrator 7.5ns 16-TSSOP
