دیتاشیت MC9S12DG256CPVE

مشخصات دیتاشیت

دانلود دیتاشیت MC9S12DT256 User Guide	MC9S12DT256 User Guide Datasheet

Manufacturer: NXP USA Inc.
Series: HCS12
Packaging: Tray
Part Status: Active
Core Processor: HCS12
Core Size: 16-Bit
Speed: 25MHz
Connectivity: CANbus, I²C, SCI, SPI
Peripherals: PWM, WDT
Number of I/O: 91
Program Memory Size: 256KB (256K x 8)
Program Memory Type: FLASH
EEPROM Size: 4K x 8
RAM Size: 12K x 8
Voltage - Supply (Vcc/Vdd): 2.35V ~ 5.25V
Data Converters: A/D 16x10b
Oscillator Type: Internal
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 112-LQFP
Supplier Device Package: 112-LQFP (20x20)
Base Part Number: MC9S1
detail: HCS12 HCS12 Microcontroller IC 16-Bit 25MHz 256KB (256K x 8) FLASH 112-LQFP (20x20)
