MAX5048AAUT+T دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MAX5048AAUT+T |
|---|---|
| حجم فایل | 103.6 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 11 |
دانلود دیتاشیت MAX5048AAUT+T |
دانلود دیتاشیت |
|---|
سایر مستندات
Part Numbering System 7 pages
MAX5048 11 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Gate Drive ICs
- Datasheet: Analog Devices Inc./Maxim Integrated MAX5048AAUT+T
- Fall Time: 12.5ns
- Load Type: MOSFET
- Rise Time: 82ns
- Supply Voltage: 4V~12.6V
- Number of Drivers: 1
- Driven Configuration: Low Side
- Operating Temperature: -40°C~+150°C@(Tj)
- Peak Output Current(sink): 7.6A
- Peak Output Current(source): 1.3A
- Package: SOT-23-6
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Current - Peak Output (Source, Sink): 1.3A, 7.6A
- Supplier Device Package: SOT-23-6
- Base Part Number: MAX5048
- Input Type: Inverting, Non-Inverting
- Gate Type: N-Channel MOSFET
- Part Status: Active
- Channel Type: Single
- Logic Voltage - VIL, VIH: -
- Series: -
- Mounting Type: Surface Mount
- Package / Case: SOT-23-6
- Packaging: Tape & Reel (TR)
- Voltage - Supply: 4V ~ 12.6V
- Rise / Fall Time (Typ): 82ns, 12.5ns
- detail: Low-Side Gate Driver IC Inverting, Non-Inverting SOT-23-6
