BAP64LX/Z,315 数据手册
其他文档
未找到其他文档！
技术规格
- Manufacturer: NXP USA Inc.
- Series: Automotive, AEC-Q101
- Packaging: Tape & Reel (TR)
- Part Status: Obsolete
- Diode Type: PIN - Single
- Voltage - Peak Reverse (Max): 60V
- Current - Max: 100mA
- Capacitance @ Vr, F: 0.3pF @ 20V, 1MHz
- Resistance @ If, F: 1.5Ohm @ 100mA, 100MHz
- Power Dissipation (Max): 150mW
- Operating Temperature: -65°C ~ 150°C (TJ)
- Package / Case: 2-XDFN
- Supplier Device Package: DFN1006D-2
- Base Part Number: BAP64
- detail: RF Diode PIN - Single 60V 100mA 150mW DFN1006D-2
