DS1868B Datasheet
Datasheet specifications
| Datasheet's name | DS1868B |
|---|---|
| File size | 426.88 KB |
| File type | |
| Number of pages | 13 |
Download Datasheet DS1868B |
Download Datasheet |
|---|
Other documentations
DS1868BE-010+T/R 13 pages
Technical specifications
- RoHS: true
- Category: ADC/DAC/Data Conversion/Digital Potentiometers
- Datasheet: Analog Devices Inc./Maxim Integrated DS1868BS-050+T/R
- Precision: ±20%
- Interface Type: serial
- Number of Taps: 256
- Supply Voltage: 2.7V~3.3V;5V
- Number of Channels: 2
- Operating Temperature: -40°C~+85°C
- Resistance Value (Ohms): 50kΩ
- Temperature Coefficient (Typ): 750ppm/°C
- Package: SO-16
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Features: -
- Supplier Device Package: 16-SO
- Configuration: Potentiometer
- Resistance (Ohms): 50k
- Tolerance: ±20%
- Package / Case: 16-SOIC (0.295", 7.50mm Width)
- Resistance - Wiper (Ohms) (Typ): 900
- Part Status: Active
- Voltage - Supply: 2.7V ~ 3.3V, 5V
- Series: -
- Interface: Serial
- Taper: Linear
- Mounting Type: Surface Mount
- Number of Circuits: 2
- Packaging: Tube
- Memory Type: Volatile
- Base Part Number: DS1868B
- detail: Digital Potentiometer 50k Ohm 2 Circuit 256 Taps Serial Interface 16-SO
