- دیتاشیت MAX17509ATJ+T
MAX17509ATJ+T دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MAX17509ATJ+T |
|---|---|
| حجم فایل | 97.333 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 24 |
دانلود دیتاشیت MAX17509ATJ+T |
دانلود دیتاشیت |
|---|
سایر مستندات
Part Numbering System 7 pages
MAX17509~ 24 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Analog Devices Inc./Maxim Integrated MAX17509ATJ+T
- Output Type: Adjustable
- Input Voltage: 4.5V~16V
- Output Voltage: 0.904V;3.782V~4.756V;5.048V
- Number of Outputs: 2
- Switching Frequency: 500kHz;1MHz;1.5MHz;2MHz
- Output Current (Max): 3A
- Operating Temperature: -40°C~+125°C@(TA)
- Synchronous Rectification: NO
- Package: TQFN-32-EP(5x5)
- Manufacturer: Analog Devices Inc./Maxim Integrated
- Voltage - Input (Max): 16V
- Voltage - Input (Min): 4.5V
- Output Configuration: Positive
- Supplier Device Package: 32-TQFN (5x5)
- Package / Case: 32-WFQFN Exposed Pad
- Frequency - Switching: 500kHz, 1MHz, 1.5MHz, 2MHz
- Current - Output: 3A
- Part Status: Active
- Series: -
- Voltage - Output (Max): 3.782V, 5.048V
- Base Part Number: MAX17509
- Mounting Type: Surface Mount
- Synchronous Rectifier: No
- Voltage - Output (Min/Fixed): 0.904V, 4.756V
- Packaging: Tube
- detail: Buck Switching Regulator IC Positive Adjustable 0.904V, 4.756V 2 Output 3A 32-WFQFN Exposed Pad
