- Datasheet LTC1844 Datasheet
LTC1844 Datasheet Datasheet
Datasheet specifications
| Datasheet's name | LTC1844 Datasheet |
|---|---|
| File size | 212.949 KB |
| File type | |
| Number of pages | 12 |
Download Datasheet LTC1844 Datasheet |
Download Datasheet |
|---|
Other documentations
LTC1844ES5-SD#TRMPBF 12 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Analog Devices LTC1844ES5-BYP#TRMPBF
- Output Type: Adjustable
- Output Current: 150mA
- Output Voltage: 1.25V~6V
- Dropout Voltage: 0.2V@(150mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 6.5V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 80uA
- Power Supply Rejection Ratio (PSRR): 50dB@(120Hz)
- Package: TSOT-23-5
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 6.5V
- Voltage - Output (Min/Fixed): 1.25V
- Voltage - Output (Max): 6V
- Voltage Dropout (Max): 0.2V @ 150mA
- Current - Output: 150mA
- Current - Quiescent (Iq): 80µA
- PSRR: 50dB (120Hz)
- Control Features: Enable
- Protection Features: Over Current, Over Temperature, Reverse Polarity, Short Circuit
- Mounting Type: Surface Mount
- Package / Case: SOT-23-5 Thin, TSOT-23-5
- Supplier Device Package: TSOT-23-5
- Base Part Number: LTC1844
- detail: Linear Voltage Regulator IC 1 Output 150mA TSOT-23-5
